Case Dimensions
- Height: 349mm (13.7 inches)
- Width: 210mm (8.3 inches)
- Depth: 372mm (14.6 inches)
- Weight: 5.9 kg (13 lb)
Component Clearance
- CPU Cooler: Maximum height of 165mm
- Graphics Card:
- Maximum length between 265mm and 325mm (depending on case configuration)
- Maximum thickness of 44mm
- Front Radiator: Maximum depth of 85mm for fans and radiator combined
Front Panel
- 1 x USB 3.2 Gen 2 Type-A port
- 1 x USB 3.2 Gen 1 Type-C port
- 1 x Headset audio jack
Fan and RGB Control
- 3 fan channels, each with a maximum power output of 10W
- 2 NZXT RGB connectors supporting up to 40 LEDs
Expansion Slots
- 2 standard expansion slots (no vertical slots)
Drive Bays
- 3 + 1 x 2.5" drive bays
- 1 x 3.5" drive bay
Cooling
- Fan Support:
- Front: 2 x 120mm or 2 x 140mm fans
- Top: 1 x 120mm fan
- Rear: 1 x 120mm fan
- All air intakes have filters
- Radiator Support:
- Front: Up to 240mm radiator
- Top: Not compatible with radiators
- Rear: Up to 120mm radiator
Pre-installed Fans (for reference only)
- Model: Aer P 120mm
- Speed: 1200 ± 200 RPM
- Airflow: 50.42 CFM
- Noise Level: 28 dBA
- Connector: 3-pin
