CPU Support:
- LGA1700 socket supporting 13th and 12th Generation Intel Core, Pentium Gold, and Celeron Processors.
- L3 cache varies with the CPU.
- Support for a wide range of Intel processors. Refer to the "CPU Support List" for compatibility details.
Memory:
- Supports DDR5 memory modules with speeds ranging from 4400 MT/s to 8000 MT/s (overclockable).
- 2 DDR5 DIMM sockets supporting up to 96 GB of system memory.
- Dual-channel memory architecture.
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode).
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules.
- Support for Extreme Memory Profile (XMP) memory modules.
- Memory configuration may depend on CPU and affect supported types and speeds.
Integrated Graphics:
- Integrated Graphics Processor-Intel HD Graphics support.
- HDMI and DisplayPort output options.
- Supports HDMI 2.0 version and HDCP 2.3.
- Supports DisplayPort 1.4 version and HDCP 2.3.
Audio:
- Realtek ALC4080 CODEC for high-quality audio.
- Support for DTS:X Ultra.
- 2-channel High Definition Audio.
LAN and Wireless:
- Intel 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps).
- Intel Killer Wi-Fi 6E AX1690 for fast wireless connectivity.
- Bluetooth 5.3 support.
- Supports multiple Wi-Fi frequencies, including 2.4/5/6 GHz carrier frequency bands.
Expansion Slots:
- CPU: 1 x PCI Express x16 slot supporting PCIe 5.0 at x16.
Storage Interface:
- CPU: 1 x M.2 connector on the back and 1 x M.2 connector on the front for storage expansion.
- Support for NVMe SSD storage devices.
- Support for RAID 0 and RAID 1 for both NVMe SSD and SATA storage devices.
- 2 x SATA 6Gb/s connectors.
USB:
- Various USB ports, including USB Type-C, USB 3.2 Gen 2x2, USB 3.2 Gen 2, and USB 2.0.
Internal Connectors:
- Multiple power connectors, fan headers, LED strip headers, and more.
- Front panel audio header routed from the adapter card on the rear panel.
Rear I/O Ports:
- Include HDMI, DisplayPort, USB ports, LAN ports, audio jacks, and more.
I/O Controller:
- iTE I/O Controller Chip for hardware monitoring, including voltage, temperature, fan speed, and more.
BIOS:
- 256 Mbit flash.
- Use of licensed AMI UEFI BIOS.
- Support for various standards and features.
Unique Features:
- Support for GIGABYTE Control Center (GCC) with various applications.
- Support for Q-Flash, Q-Flash Plus, and Smart Backup.
Bundled Software:
- Norton Internet Security (OEM version).
- LAN bandwidth management software.
Operating System Support:
- Compatible with Windows 11 64-bit and Windows 10 64-bit.
Form Factor:
- Mini-ITX Form Factor measuring 17.0cm x 17.0cm.
