| CPU / Socket | 2 x Socket R3 (LGA 2011-3; Square, 80x80mm) |
| CPU Support | Intel Xeon E5-2600 v4 series |
| Intel Xeon E5-2600 v3 series | |
| QPI | 6.4 / 8.0 / 9.6 GT/s |
| Cores | Intel C612 PCH |
| Memory | Total Slots: 8 (4 channels per CPU, 4 DIMMs per CPU) |
| Capacity: Up to 512GB LRDIMM | |
| Memory Type | DDR4 2400 / 2133 / 1866 / 1600 / 1333 RDIMM |
| DDR4 2400 / 2133 / 1866 / 1600 / 1333 LRDIMM | |
| Memory Capacity | 32GB, 16GB, 8GB, 4GB RDIMM |
| 64GB, 32GB LRDIMM | |
| Expansion Slots | Total Slots: 3 |
| Slot 1: PCI-E x8 (x4 Gen2) with MIO support | |
| Slot 5: PCI-E x16 (x16 Gen3) | |
| Slot 6: PCI-E x8 (x8 Gen3) | |
| Form Factor | CEB (12" x 10.5", ATX layout) |
| ASUS Features | Fan Speed Control, Ready for brackets and supports, ASWM Enterprise |
