BẢNG THÔNG SỐ CHI TIẾT:
| Unique Feature | Superb Productivity, Rock-Solid Durability, Ultrafast Connectivity, EZ Troubleshooter |
| CPU | Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700), Intel® Hybrid Technology, Turbo Boost Max 3.0 Technology, Thermal Velocity Boost (TVB), Adaptive Boost Technology (ABT) |
| Chipset | Intel® Z790 |
| Memory | Dual Channel DDR4 Memory Technology, 4 x DDR4 DIMM Slots, Supports DDR4 non-ECC, un-buffered memory up to 5333+(OC), Max. capacity of system memory: 128GB, Supports Intel® XMP 2.0 |
| BIOS | 128Mb AMI UEFI Legal BIOS with GUI support |
| Graphics | Intel® Xe Graphics Architecture (Gen 12), 1 x eDP 1.4, 1 x HDMI 2.1 TMDS Compatible (with processor GPU integrated) |
| Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio |
| LAN | 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125BG), Supports Phantom Gaming LAN Software, Smart Auto Adjust Bandwidth Control, Visual Network Usage Statistics, Optimized Default Setting for Game, Browser, and Streaming Modes, User Customized Priority Control |
| Slots | CPU: 1 x PCIe 5.0 x16 Slot (PCIE1), Chipset: 1 x PCIe 4.0 x16 Slot (PCIE4), 3 x PCIe 3.0 x1 Slots, 1 x M.2 Socket (Key E) |
| Storage | CPU: 1 x Hyper M.2 Socket (M2_1), Chipset: 1 x Hyper M.2 Socket (M2_2), 1 x Hyper M.2 Socket (M2_3), 1 x Hyper M.2 Socket (M2_4), 4 x SATA3 6.0 Gb/s Connectors |
| RAID | Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices, Supports RAID 0, RAID 1, and RAID 5 for M.2 NVMe storage devices |
| USB | 1 x USB 3.2 Gen2x2 Type-C (Rear), 1 x USB 3.2 Gen2 Type-A (Rear), 1 x USB 3.2 Gen1 Type-C (Front), 9 x USB 3.2 Gen1 Type-A (5 Rear, 4 Front), 3 x USB 2.0 (1 Rear, 2 Front) |
| Connectors | Various connectors including eDP Signal Connector, SPI TPM Header, Power LED and Speaker Header, RGB LED Header, Addressable LED Headers, CPU Fan Connector, CPU/Water Pump Fan Connector, Chassis/Water Pump Fan Connectors, 24 pin ATX Power Connector, 2 x 8 pin 12V Power Connectors, Front Panel Audio Connector, Thunderbolt™ AIC Connector, USB Headers |
| Rear Panel I/O | 2 x Antenna Mounting Points, PS/2 Mouse/Keyboard Port, HDMI Port, USB Ports, RJ-45 LAN Port, HD Audio Jacks |
| Software and UEFI | ASRock Motherboard Utility, ASRock Phantom Gaming LAN Software, ASRock Polychrome SYNC, ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Auto Driver Installer, ASRock Instant Flash, ASRock Easy RAID Installer |
| Accessories | User Manual, SATA Data Cables, Screws for M.2 Sockets, Standoff for M.2 Socket |
