| Unique Feature | ASRock USB4 Thunderbolt™ 4 Type-C Port (40 Gb/s for USB 4.0 protocol; 40Gb/s for Thunderbolt™ protocol) |
| ASRock USB 3.2 Gen2 | - ASRock Front Panel Type-C USB 3.2 Gen2x2 Header (20 Gb/s) - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) |
| ASRock Super Alloy | - XXL Aluminum Alloy Heatsink - Premium Power Choke - 105A SPS (Smart Power Stage) - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron power choke) - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB - 12 Layer PCB - 2oz Copper PCB |
| AQUA Cooling Armor | Server-Grade Low-Loss PCB |
| Marvell (Aquantia) 10G LAN | AQUANTIA® 10G LAN |
| Killer 2.5G LAN | 802.11ax Wi-Fi 6E |
| Killer DoubleShot™ Pro | ASRock Auto Driver Installer |
| ASRock Steel Slots | ASRock Full Coverage M.2 Heatsink |
| ASRock Hyper M.2 (PCIe Gen4x4) | ASRock Ultra USB Power |
| ASRock Status OLED | ASRock Full Spike Protection (for all USB, Audio, LAN Ports) |
| ASRock Live Update & APP Shop | CPU - Supports 13th Gen & 12th Gen and next-gen Intel® Core™ Processors (LGA1700) - Digi Power design - 20 Power Phase design - Supports Intel® Hybrid Technology - Supports Intel® Turbo Boost Max 3.0 Technology - Supports ASRock Hyper BCLK Engine V |
| Chipset | Intel® Z690 |
| Memory | - Dual Channel DDR5 Memory Technology - 4 x DDR5 DIMM Slots - Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC)* - Max. capacity of system memory: 192GB - Supports Intel® Extreme Memory Profile (XMP) 3.0 - 15μ Gold Contact in DIMM Slots |
| BIOS | - 256Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake-up events - SMBIOS 2.7 Support - Voltage Multi-adjustment for various components |
| Graphics | - Intel® Xe Graphics Architecture (Gen 12) - Supports Intel® Thunderbolt™ 4 with max. resolution up to 8K (7680x4320) @ 60Hz** - Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz - Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and Intel® Thunderbolt™ 4 Ports |
| Audio | - 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - WIMA Audio Capacitors (For Front Outputs) - ESS SABRE9218 DAC for Front Panel Audio (130dB SNR) - Gold Audio Jacks - Nahimic Audio |
| LAN |
