Thông số kỹ thuật
⚙ THÔNG SỐ CƠ BẢN:
- Socket: AM5
- Số nhân: 6
- Số luồng: 12
-
MÔ TẢ SẢN PHẨM
Processor Specifications:
- Platform: Desktop
- Product Family: AMD Ryzen™ Processors
- Product Line: AMD Ryzen™ 5 8000 G-Series Desktop Processors with Radeon™ Graphics
- AMD PRO Technologies: No
- Consumer Use: Yes
- Regional Availability: Global
- Former Codename: "Phoenix"
- Architecture: "Zen 4"
- # of CPU Cores: 6
- Multithreading (SMT): Yes
- # of Threads: 12
- Max. Boost Clock: Up to 5.0GHz
- Base Clock: 4.3GHz
- L2 Cache: 6MB
- L3 Cache: 16MB
- Default TDP: 65W
- AMD Configurable TDP (cTDP): 45-65W
- Processor Technology for CPU Cores: TSMC 4nm FinFET
- CPU Compute Die (CCD) Size: 178mm²
- Package Die Count: 1
- Unlocked for Overclocking: Yes
- AMD EXPO™ Memory Overclocking Technology: Yes
- Precision Boost Overdrive: Yes
- Curve Optimizer Voltage Offsets: Yes
- AMD Ryzen™ Master Support: Yes
- CPU Socket: AM5
- CPU Boost Technology: Precision Boost 2
- Instruction Set: x86-64
- Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
- Max. Operating Temperature (Tjmax): 95°C
- Operating System (OS) Support:
- Windows 11 - 64-Bit Edition
- Windows 10 - 64-Bit Edition
- RHEL x86 64-Bit
- Ubuntu x86 64-Bit
Connectivity:
- Native USB 4 (40Gbps) Ports: 2
- Native USB 3.2 Gen 2 (10Gbps) Ports: 2
- Native USB 2.0 (480Mbps) Ports: 1
- PCI Express® Version: PCIe® 4.0
- Native PCIe® Lanes (Total/Usable): 20 / 16
- NVMe Support: Boot, RAID0, RAID1
- System Memory Type: DDR5
- Memory Channels: 2
- Max. Memory: 256GB
- System Memory Subtype: UDIMM
- Max Memory Speed:
- 2x1R DDR5-5200
- 2x2R DDR5-5200
- 4X1R DDR5-3600
- 4x2R DDR5-3600
Graphics Capabilities:
- Integrated Graphics: Yes
- Graphics Model: AMD Radeon™ 760M
- Graphics Core Count: 8
- Graphics Frequency: 2800 MHz
- DirectX® Version: 12
- DisplayPort™ Version: 2.1
- HDMI® Version: 2.1
- HDCP Version Supported: 2.3
- USB Type-C® DisplayPort™ Alternate Mode: Yes
- Multi-Monitor Support: Yes
- Max Displays: 4
- AMD FreeSync™: Yes
- Wireless Display: Miracast
Video Encode and Decode Bandwidth:
- Max Video Encode Bandwidth (SDR):
- 1080p630 8bpc H.264
- 1440p373 8bpc H.264
- 2160p175 8bpc H.264
- 1080p630 8bpc H.265
- 1440p373 8bpc H.265
- 2160p175 8bpc H.265
- 4320p43 8bpc H.265
- 1080p864 8/10bpc AV1
- 1440p513 8/10bpc AV1
- 2160p240 8/10bpc AV1
- 4320p60 8/10bpc AV1
- Max Video Decode Bandwidth:
- 1080p60 8bpc MPEG2
- 1080p60 8bpc VC1
- 1080p786 8/10bpc VP9
- 2160p196 8/10bpc VP9
- 4320p49 8/10bpc VP9
- 1080p1200 8bpc H.264
- 2160p300 8bpc H.264
- 4320p75 8bpc H.264
- 1080p786 8/10bpc H.265
- 2160p196 8/10bpc H.265
- 4320p49 8/10bpc H.265
- 1080p960 8/10bpc AV1
- 2160p240 8/10bpc AV1
- 4320p60 8/10bpc AV1
AMD SmartAccess Memory:
- Yes
AI Engine Capabilities:
- Brand Name: AMD Ryzen™ AI
- Available Performance: Up to 16 TOPS
